#include <Accumulator.h>
The accumulator is a new system to replace filters. Used for accumulating network statistics, byte counts, etc. It uses uint64_t to be useful in a wider variety of situations (without wrapping).
Common usage:
// in main() Log::add(Accumulator::NETWORK_READ_SELECTOR); Accumulator::startLogging(); //causes periodic logs of the accumulator values // elsewhere Accumulator* a = Accumulator::Instance(Accumulator::NETWORK_READ); while (true) { int r = ::read(fd, buf, size); if (r > 0) { a->accumulate(r); } }
Each accumulator will log values with a selector of the format "Accumulator::SELECTORNAME". So there are two variables for the basic accumulators, one with the accumulator name, one with the selector name.
Definition at line 79 of file Accumulator.h.
Public Member Functions | |
void | startTimer () |
call to begin a timer for accumulators | |
void | stopTimer () |
disables the timer started with startTimer() | |
void | accumulate (unsigned int amount) |
adds amount to the accumulator | |
void | accumulateUnlocked (unsigned int amount) |
adds amount to the accumulator | |
uint64_t | getAmount () const |
returns the current accumulator amount | |
uint64_t | getDiff () const |
returns the amount since diff was last reset | |
uint64_t | resetDiff () |
returns the amount since diff was last reset and also resets diff. | |
uint64_t | getStartTime () |
returns the startTime for the timer | |
uint64_t | getLastTime () |
returns the lastTime for the timer | |
Static Public Member Functions | |
static Accumulator * | Instance (const std::string &counter) |
returns an accumulator for the given counter string | |
static void | dumpAll () |
prints all values in text to selector "Accumulator::dumpAll" | |
static void | logAll () |
prints all values to their specific accumulator | |
static void | startLogging (uint64_t interval=1 *1000 *1000) |
begins the logging thread | |
static void | stopLogging () |
ends the logging thread. Must br called after start for clean shutdown. | |
Static Public Attributes | |
static const std::string | NETWORK_READ = "NETWORK_READ" |
accumulates bytes from all transports reading | |
static const std::string | NETWORK_READ_SELECTOR = "Accumulator::NETWORK_READ" |
selector for Accumulator::NETWORK_READ | |
static const std::string | NETWORK_WRITE = "NETWORK_WRITE" |
accumulates bytes from all transport writing | |
static const std::string | NETWORK_WRITE_SELECTOR = "Accumulator::NETWORK_WRITE" |
selector for Accumulator::NETWORK_WRITE | |
static const std::string | TCP_READ = "TCP_READ" |
accumulates bytes from all TCP transpot reads | |
static const std::string | TCP_READ_SELECTOR = "Accumulator::TCP_READ" |
selector for Accumulator::TCP_READ | |
static const std::string | TCP_WRITE = "TCP_WRITE" |
accumulates bytes from all TCP transport writes | |
static const std::string | TCP_WRITE_SELECTOR = "Accumulator::TCP_WRITE" |
selector for Accumulator::TCP_WRITE | |
static const std::string | UDP_READ = "UDP_READ" |
accumulates bytes from all UDP transpot reads | |
static const std::string | UDP_READ_SELECTOR = "Accumulator::UDP_READ" |
selector for Accumulator::UDP_READ | |
static const std::string | UDP_WRITE = "UDP_WRITE" |
accumulates bytes from all UDP transport writes | |
static const std::string | UDP_WRITE_SELECTOR = "Accumulator::UDP_WRITE" |
selector for Accumulator::UDP_WRITE | |
static const std::string | HTTP_CLIENT_READ = "HTTP_CLIENT_READ" |
accumulates bytes from HTTP reads | |
static const std::string | HTTP_CLIENT_READ_SELECTOR |
selector for Accumulator::HTTP_CLIENT_READ | |
static const std::string | HTTP_CLIENT_WRITE = "HTTP_CLIENT_WRITE" |
accumulates bytes from HTTP writing | |
static const std::string | HTTP_CLIENT_WRITE_SELECTOR |
selector for Accumulator::HTTP_CLIENT_WRITE | |
static const std::string | HTTP_SERVER_READ = "HTTP_SERVER_READ" |
accumulates bytes from HTTP server reading | |
static const std::string | HTTP_SERVER_READ_SELECTOR |
selector for Accumulator::HTTP_SERVER_READ | |
static const std::string | HTTP_SERVER_WRITE = "HTTP_SERVER_WRITE" |
accumulates bytes from HTTP server writing | |
static const std::string | HTTP_SERVER_WRITE_SELECTOR |
selector for Accumulator::HTTP_SERVER_WRITE | |
static const std::string | TRANSPORT_SEND = "TRANSPORT_SEND" |
accumulates bytes enqueued in the transports | |
static const std::string | TRANSPORT_SEND_SELECTOR = "Accumulator::TRANSPORT_SEND" |
selector for Accumulator::TRANSPORT_SEND | |
static const std::string | TRANSPORT_RECV = "TRANSPORT_RECV" |
accumulates bytes delivered from the transports | |
static const std::string | TRANSPORT_RECV_SELECTOR = "Accumulator::TRANSPORT_RECV" |
selector for Accumulator::TRANSPORT_RECV | |
static const std::string | TRANSPORT_RECV_CANCELED = "TRANSPORT_RECV_CANCELED" |
accumulates bytes received for cancelled messages | |
static const std::string | TRANSPORT_RECV_CANCELED_SELECTOR = "Accumulator::TRANSPORT_RECV_CANCELED" |
selector for Accumulator::TRANSPORT_RECV_CANCELED | |
static const std::string | FILE_WRITE = "FILE_WRITE" |
accumulates bytes written from the file util | |
static const std::string | FILE_WRITE_SELECTOR = "Accumulator::FILE_WRITE" |
selector for Accumulator::FILE_WRITE | |
static const std::string | APPLICATION_RECV = "APPLICATION_RECV" |
intended for use by applications to measure goodput received | |
static const std::string | APPLICATION_RECV_SELECTOR = "Accumulator::APPLICATION_RECV" |
selector for Accumulator::APPLICATION_RECV | |
static const std::string | APPLICATION_SEND = "APPLICATION_SEND" |
intended for use by applications to measure goodput sent | |
static const std::string | APPLICATION_SEND_SELECTOR = "Accumulator::APPLICATION_SEND" |
selector for Accumulator::APPLICATION_SEND | |
static const std::string | DB_WRITE_BYTES = "DB_WRITE_BYTES" |
accumulates bytes written from a db | |
static const std::string | DB_WRITE_BYTES_SELECTOR = "Accumulator::DB_WRITE_BYTES" |
selector for Accumulator::DB_WRITE_BYTES | |
static const std::string | DB_WRITE_COUNT = "DB_WRITE_COUNT" |
accumulates writes to a db | |
static const std::string | DB_WRITE_COUNT_SELECTOR = "Accumulator::DB_WRITE_COUNT" |
selector for Accumulator::DB_WRITE_COUNT | |
static const std::string | DB_ERASE_COUNT = "DB_ERASE_COUNT" |
accumulates erases to a db | |
static const std::string | DB_ERASE_COUNT_SELECTOR = "Accumulator::DB_ERASE_COUNT" |
selector for Accumulator::DB_ERASE_COUNT |
void Accumulator::startTimer | ( | ) | [inline] |
call to begin a timer for accumulators
the first call to accumulateUnlocked() after startTimer() sets startTime (and each call sets lastTime). This is so you can see the amount accumulated between startTime and endtime, without bias for time passing without accumulation.
Clear the timer using stopTimer();
Definition at line 147 of file Accumulator.h.
void Accumulator::accumulate | ( | unsigned int | amount | ) | [inline] |
adds amount to the accumulator
Calls accumulateUnlocked() after acquring a lock. This is because it is unsafe to call accumulate multithreaded without synchronization.
amount | amount to add to the accumulator |
Definition at line 163 of file Accumulator.h.
References accumulateUnlocked().
void Accumulator::accumulateUnlocked | ( | unsigned int | amount | ) | [inline] |
adds amount to the accumulator
Caller promises to not call accumulateUnlocked from two threads at the same time. If that may occur, caller should use accumulate() instead.
amount | amount to add to the accumulator |
Definition at line 176 of file Accumulator.h.
References TimeUtil::timeu().
Referenced by accumulate().
